5 Watt DC Converter brick module with 24VDC input and 15V output at half price

5 watt DC/DC converter module

Click here for a larger view of the DC/DC converter
These printed circuit mount dc to dc converter bricks closely regulate the output voltage over a range of input voltages.

Isolated DC converter modules with 24V input and single 15V output


AA05E-024L-150S 15V output 0.33A 5W $11 Add to cart
Data Value
Input voltage 24V 18V to 36V
Output voltage 15V 0.67A 5 Watts
Setpoint accuracy ±1%
Voltage adjust none
Line regulation ±0.5%
Load regulation ±1%
Noise <1% mV p-p
Ripple <20 mV rms
Transient response 200 microsecond max for a 25% step
Short circuit protection Continuous current limit
Overvoltage protection Zener clamp
Temperature -40°C to 85°C operating -40°C to 105°C storage
Agency approval UL60950, CSA22.2-60950, TUV EN60950
Data Sheet Full data sheet here
Isolation 1500V, 1 gigohm
Weight 15g, 0.5 oz
Switching Frequency 200 kHz
Efficiency ~85%
MTBF > 1 million hours Bellcore TR332

Advantages:

OEM Battery Chargers Inexpensive Switchmode 24 volt to 15V DC/DC Converter

OEM Battery Chargers High efficiency: approximately 85%.

Universal Power Input OEM Power Supplies and OEM Battery Chargers Wide input voltage range.
