40 Watt 24VDC to 24VAC Pure Sine Wave DC/AC Inverter for CCTV

Low power, low voltage 24VAC inverters
More 24VAC low voltage power inverters with 12V input, 24V input and 48V input, 40 Watts and 100 Watts
12 volt to 24 VAC inverter
Unique 24 volt AC inverter rated at 40 watts for use with CCTV and Solar installations. Suitable for 24VAC irrigation systems, and even 24VAC doorbells. Converts 24 volt dc to 24 volts AC.
12VDC to 24VAC inverters and 48VDC to 24VAC inverters are also available

Quantity   1-9 10-99 100-499 500+
PST-INV2424 40 watt inverter, 24VDC in, 24VAC out $100.00
$89.00 $72.00 $64.00
PST-INV2424-50Hz
(allow 1-2 weeks)
50 Hz version of the forty watt 24 volt DC to 24 volt AC inverter $100.00
$89.00 $72.00 $64.00
PST-INV2424-400Hz
(allow 1-2 weeks)
400 Hz $110
$95.00 $73.00 $64.00

PST-INV2424 Function: DC/AC Inverter with 24VAC output
Country of Origin USA, NAFTA qualified
Output power 40VA continuous (40 Watts) (24VAC 1.6Amps nominal)
50VA for 1 minute at 50% duty factor( 1 minute above 40VAC, one minute below 40VA
Output Current 1.6 Amps continuous, 2 amps peak
Input voltage DC 22VDC to 29VDC start-up,
20VDC to 30VDC operating.
Output voltage AC 24VAC
Output voltage regulation ± 10%
Output wave form Pure sine wave
Output frequency 60Hz ± 1% (50Hz, 400Hz available)
Standby current 0.2A, 200 mA typical
Efficiency 90% max.
Operating Temperature -10°C to +45°C
Cooling Convection cooling, no fan
Protections Output short
Polarity reverse
Under voltage input
Under voltage protection Unit will shut itself down when the input voltage is less than 20VDC ±5%. It will restart when the voltage is above 22VDC
DC Input Screw terminals
AC output Screw Terminals
Isolation DC input is galvanically isolated from the AC output, greater than 100V hipot
Dimensions 132 X 75 X 38 mm , 5.2 x 3 x 1.5 inches
Weight 277 gms., 10oz, 0.6 lbs
Drawing Drawing and Mounting dimensions click here
More options Please ask if you need different input voltages, output voltage, output power, surge protection, connectorization, or form factor.

Advantages:

OEM Battery Chargers Inexpensive DC/AC power inverter light weight and small size will convert 24vdc to 24vac.

OEM Battery Chargers Makes 24 VAC equipment usable in 24 VDC installations. DC to AC inverter can work with solar or battery back-up systems.

OEM Power Supplies Useful for solar powered security systems. Also useful for irrigation system controllers.

Universal Power Input OEM Power Supplies and OEM Battery Chargers This product is now in production
