| DC-DC
Converters |
Heavy
Duty
5 Amp
DC to DC Converter
 |
Marine Grade
5 Amp
DC to DC Converter |
Military Grade
5 Amp
DC to DC Converter
|
|
Part Number
and Price |
PVTC72-24-12
$237
Allow up to 15 days for shipping
|
PVTC72-24-12-WP
$273
Allow up to 15 days for shipping
|
PVTC72-24-12-MIL
$308
Allow up to 15 days for shipping
|
Part Number |
| Input Voltage |
20 to 35VDC |
20 to 35 VDC |
20 to 35 VDC |
Input Voltage) |
| Max Input current at No Load |
|
mA |
mA |
Max Input current at No Load |
| Output Voltage |
13.6 VDC
(12V
available, ask at time of order) |
13.6 VDC
(12V
available, ask at time of order) |
13.6 VDC
(12V
available, ask at time of order) |
Output Voltage |
| Output Adjustment |
|
|
|
Output Adjustment |
| Max Output Current(s) |
7 Amps for 10 minutes
maximum |
7 Amps for 10 minutes
maximum |
7 Amps for 10 minutes
maximum |
Max Output Current |
| Max Output Power |
97 watts |
97 watts |
97 watts |
Max Output Power (10 Minutes) |
| Max Output Power (continuous) |
70 Watts
(5
Amps) |
70 Watts
(5
Amps) |
70 Watts
(5
Amps)) |
Max Output Power (continuous) |
| Output current limit? |
Yes |
Yes |
Yes |
Output current limit? |
| Output voltage protection |
Crowbars at 16V
± 0.5V |
Crowbars at 16V
± 0.5V |
Crowbars at 16V
± 0.5V |
Output voltage protection |
| Operating Temperature Range |
-25°C to
+45°C |
-25°C to
+45°C |
-40°C to
+55°C |
Operating Temperature Range |
| Derating |
|
|
-2.5% per degree C
from +55°C to +85°C |
|
| Efficiency |
>88 % |
>88 % |
>88 % |
Efficiency |
| Isolation |
Common
negative
>500 volts from case to any terminal |
Common
negative
>500 volts from case to any terminal |
Common
negative
>500 volts from case to any terminal |
|
| Line Regulation |
<±0.5% |
<±0.5% |
<±0.5% |
Line Regulation |
| Load Regulation |
<±0.5% |
<±0.5% |
<±0.5% |
Load Regulation |
| Switching frequency |
kHz |
kHz |
kHz |
Switching frequency |
| Output ripple noise |
<10 mV rms |
<10 mV rms |
<10 mV rms |
Output ripple noise |
| Noise imposed on input terminals |
<10 mV rms |
<10 mV rms |
<10 mV rms |
Noise imposed on input terminals |
| Remote power on/off |
No |
No |
No |
Remote power on/off |
| Connections |
Screw terminals |
Screw terminals |
Screw terminals |
Connections |
| Protection |
Over Voltage , Over Current, Short Circuit , Reverse Polarity , Over Load |
Over Voltage , Over Current, Short Circuit , Reverse Polarity , Over Load |
Over Voltage , Over Current, Short Circuit , Reverse Polarity , Over Load |
Protection |
| Input Fuse |
10 Amps AGC |
10 Amps AGC |
10 Amps AGC |
Input Fuse |
| Dimensions |
105 x
109 x 49 mm
(4.12 x 4.3 x 1.89 inches) |
105 x
109 x 49 mm
(4.12 x 4.3 x 1.89 inches) |
105 x
109 x 49 mm
(4.12 x 4.3 x 1.89 inches) |
Dimensions |
| Drawings |
Click Here for Drawing
|
Click Here for Drawing
|
Click Here for Drawing
|
Drawings |
| Weight |
0.28 Kg (0.62
lbs) |
|
|
Weight |
| Audible Noise |
None |
None |
None |
|
| Case |
Marine grade
aluminum, Black Anodize and Powder Epoxy Coat |
|
| Additional Features |
|
|
|
Additional Features |
Heavy Duty
Switchmode DC/DC Converters.
