AC/DC Switching Adapters 15 Watt

Custom design and manufacture of state-of-the-art battery chargers, UPS, and power supplies for OEMs in a hurry!

AC Power Adapter for Laptops

AC /DC Adpaters 15 Watt nominal, Desktop and Wall Mount

15 Watt Switching Wall Mount & Desktop AC/DC Power Supplies
Model No.   Output Output Current Maximum SAFETY CASE
    Voltage Maximum Output Power UL TUV CB PSE CE Click for Drawings
JOD-SAX040252   4.0V 2.5A 10W ¤ ¤ ¤ ¤ ¤ 0Z,1Z, 2Z, 3Z
JOD-SAX050152   5.0V 1.5A 7.5W ¤ ¤ ¤ ¤ ¤ 0Z,1Z, 2Z, 3Z
PST-AC0505W Data 5.0V 0.5A 2.5W ¤           4Z
PST-AC0520 Data 5.0V 2.0A 10W ¤ ¤ ¤ ¤ ¤ 1Z
JOD-SAX050262   5.0V 2.6A 13W ¤     ¤   1Z
JOD-SAX050302   5.0V 2.5A 12.5W ¤ ¤ ¤ ¤ ¤ 0Z,1Z, 2Z, 3Z
JOD-SAX040252   5.0V 3.0A 15W ¤ ¤ ¤ ¤ ¤ 0Z,1Z, 2Z, 3Z
JOD-SAX063222   6.3V 2.2A 13.86W ¤ ¤ ¤ ¤ ¤ 0Z,1Z, 2Z, 3Z
JOD-SAX072202   7.18V 2.0A 14.36W ¤ ¤ ¤ ¤ ¤ 0Z,1Z, 2Z, 3Z
PST-AC09013 Price and Data 9.0V 1.3A 12W ¤   ¤   ¤ 4Z
JOD-SAX090162   9.0V 1.6A 14.4W ¤ ¤ ¤ ¤ ¤ 0Z,1Z, 2Z, 3Z
JOD-SAX120132   12.0V 1.25A 15W ¤ ¤ ¤ ¤ ¤ 4Z
JOD-SAX120152   12.0V 1.5A 18W ¤ ¤ ¤ ¤ ¤ 0Z,1Z, 2Z, 3Z
JOD-SAX150102   15.0V 1.0A 15W ¤ ¤ ¤ ¤ ¤ 0Z,1Z, 2Z, 3Z
JOD-SAX180082   18.0V DC 0.8A 14.4W ¤ ¤ ¤ ¤ ¤ 0Z,1Z, 2Z, 3Z
PST-AC2405W Data 24.0V DC 0.5A 12W ¤         4Z

Specifications
INPUT Input voltage : 90 to 264Vac (Wide range)
Input Frequency : 47Hz~63Hz
Input current : 0.45A
Input inrush current : 30A at 115Vac,60A at 230Vac
Efficiency : >70% at Full Load
OUTPUT
Output Rating : See Rating Charts
Output Volatge : +4V~+24VDC
Output current : 0.2A~3.0A
Line Regulation : 1%
Load Regulation : 5%
Ripple & Noise : 1% P-P max
Hold-up time : >10ms at full load, 115VAC
PROTECTION
Over Voltage Protection
Short circuit Protection
Auto recovery
SAFETY
UL 60950 TUV EN60950
Level B EMI Filter Conduction
EMI/RFI:CISPR 22& FCC Class B limits
 Environmental
  OPERATION TEMEPERATURE : 0° to 40°
  MTBF : 50000 hours, at full load and 25?
  100% burn-in and tested.

Connector Types
I. D O. D Long Straight Right Angle Type
No.
1 2.1 5.5 V V Barrel
2 2.5 5.5 V V Barrel
3   3.5   V Barrel
4 2.1 5.0 V V Barrel
5 2.5 5.0 V V Barrel
6 1.3 3.5 V V Barrel
7 1.0 3.5 V V Barrel
8 1.0 3.8 V V Barrel
9 0.7 2.35 9.5 V V New EIAJ Female
10 1.7 4.0 9.5 V V New EIAJ Female
11 1.7 4.75 9.5 V V New EIAJ Female
12 1.0 5.5 9.5 V V New EIAJ Female
13 1.4 6.5 9.5 V V New EIAJ Female
ISO-9001 Certified Factory
