November 17, 2017

12 Volt 22AH Lithium Iron Phosphate. High Capacity Rechargeable Lithium Replacement for SLA Batteries


Lithium replacement for SLA and Gel batteries from PowerStream with high capacity and high power
More lithium replacements for SLA batteries
12 Volt 50 Amp hour lithium iron phosphate battery 19 lbs
12V 50AH lithium iron phosphate pack 19 lbs
12V 22AH Lithium Iron Phosphate lead acid replacement

New exclusive feature: they can be used in series up to 48V.

22 AH battery which can source up to 100 amps. Suitable for starting motor batteries **.

These li-ion cells and batteries not only have high capacity, but can deliver high power. High-power lithium iron phosphate batteries are now a reality. They can be used as storage cells or power sources.

In addition, Lithium Iron Phosphate batteries are among the longest lived batteries ever developed. Test data in the laboratory show up to 2000 charge/discharge cycles. Our cells typically have more than 1000 cycles in service.

These batteries are excellent for use in motorcycles, snowmobiles, jet skis, etc., (see applicaiton note below) because they do not need maintenance during the off season. There is no equivalent to sulfation and the batteries can be stored in any state of charge without worry of degradation. We recommend 50-100% charge before storage. Another advantage is that running the battery completely down (i.e. leaving the parking light on for a week) will not damage the battery at all, unlike the SLA and Gel batteries.
Prices Quantity 1-10 11-50 51+
LFP1222Y (replaces LFP128198) add_to_cart.gif $295 $268 $250
12V 1.3A lithium iron phosphate battery chargers
12V, 1.3A Wall mount lithium iron phosphate battery charger.
Will charge the LFP128198 in about 15 hours
LiFePO4 battery charger, 12V 3.2 Amps
12V 3.2A Desktop lithium iron phosphate battery charger.
Will charge the LFP128198 in about 6 hours.

Advantages and Benefits:

  • Longer battery life - will last 5x longer than an equivalent SLA or VRLA battery
  • Lightweight - 1/2~1/4 the weight compared to lead acid batteries
  • Can be safely charged with a lead acid battery charging system
  • Safer than traditional lithium ion batteries, hermetically sealed
  • Low self-discharge
  • No memory effect
  • Maintains higher voltage during discharge than lead acid
  • Can store at any state of charge without degradation
  • Wide temperature performance
  • Built in short circuit protection
  • Built in over charge and over discharge protection
  • Built in over current protection
  • Product Type: Replacement for 12V 17Ah Lead Acid Battery
  • Applications: Perfect for motorcycle starter, 12VDC power, medical equipment, LED light power supply, solar power

Note: these can be used in parallel to increase the capacity, AND they can be used in series to increase the voltage up to 48V.
Parameter
Item # LFP128198

Battery Type:

Lithium-Iron Phosphate (LiFePO4)

Nominal Voltage:

 12.8V
Voltage range during discharge 14.6V to 10V
Capacity: 22Ah
Weight: 2.75 kg 6.06 lbs SLA is typically 14.5 lbs
Dimension (L x W x H) 181x76x166 mm 7.13x2.99x6.54 inches

Warranty:

30-Day Money Back Guarantee. Full One Year Warranty.
Cycle Life 1200+ discharge cycles to 20% remaining
Charge Method CC/CV to 14.6V Will work with modern lead acid chargers including automotive charging systems
Maximum charge current 20 Amps
Normal charge current 4 Amps Lower charge currents are OK
Maximum Pulse Discharge Current 100 Amps 30 seconds max
Maximum continuous discharge current 40 Amps
Nominal continuous discharge current 10 Amps
Operation Temperature Charging 0°C to 60°C
Discharging -10°C to 60°C
Storage Temperature 0°C to 25°C 1 year
  -5°C to 35°C 3 months
Mounting position Can be mounted on any side, or upside-down


This LiFePO4 battery will replace the following sealed lead acid batteries
BP17-12
BC18-12
BP20-12
HR22-12
EP12-12
EB20-12
EVP20-12
BPL17-12
EVX-12170
CFM12V18
PE12V18B1
PX12180
PWL12V15
HP15-12
JC12150
LC-R12V17P
LC-RD1217P
LC-X1220P
LC-X1220AP
PS-12150
PS-12180
A212/15G
A512/10.0SR
UB12180
KB12170
NP18-12B
NP20-12
NPG18-12
NPH16-12
NPX-80


** Application note:

Starting small engines. This battery will source 100+ amps during engine starting, which is over one horsepower. This is plenty of power to start most small engines. HOWEVER we have found that this might not be enough to start some high compression engines, particularly motorcycle racing engines and even some lawn mower engines. Please verify the current you need before ordering, because we will charge you a 15% restocking fee plus shipping if you return it.

Using these batteries in series.

Most manufacturers of similar batteries cannot allow the battery to be used in series. We have developed a new battery management board capable of supporting up to 48V, so these batteries can be put in 12V, 24V, 36V, or 48V combinations by placing them in series. This is helpful in electric bikes, wheel chairs, and other higher voltage appliances. They can also be put in series-parallel combination, just like sealed lead acid batteries. Before putting them in series it is best to fully charge each battery at 12V (14.6V peak) to make sure they start out balanced.

More Advantages:

OEM Battery Chargers State of the art lithium-iron-phosphate packs cell with laser welded stainless steel cases, in a standard size sealed lead acid plastic case

Universal Power Input OEM Power Supplies and OEM Battery Chargers High Discharge rates

Universal Power Input OEM Power Supplies and OEM Battery Chargers Cycle life 1000 to 2000 cycles.

Universal Power Input OEM Power Supplies and OEM Battery Chargers Much safer than any other lithium ion technology
